External IP in Azure when clustered

Alocaurd

New Member
Jun 25, 2019
13
0
1
32
I made a cluster in Azure with 4 nodes using the latest logical master-master replication successfully.

However, in Azure, i need to set the external RTP and SIP IP address in the variables, but it looks like that information is replicated, so one IP is applied to all servers. Is there another way around this?


Neyamt

Member
Nov 12, 2021
44
1
8
28
You need to exclude v_sip_profile_settings table to not be sync in the cluster. I have done this solution using asynchronization clustering methods between two server as active/active (Not membership solution of the FusionPBX). because it will not be unavailable after discontinuing subscription of the membership.


ardyhash

Member
Jan 7, 2021
39
6
8
44
@Alocaurd, any chance you're open to sharing notes/documentation about how you went about setting up a cluster?
@Neyamt sounds like you've got some real world experience with clustering, any and all resources you can point me to regarding a highly available or load balanaced FusionPBX cluster would be greatly appreciated.


DigitalDaz

Administrator
Staff member
Sep 29, 2016
3,032
554
113
You do not need to exclude tables from the replication, see the following post, you can include local files that are local to the server to set the local ips:


  • Like
Reactions: Neyamt and ardyhash
